18-16 Profile Software User's Guide

CONFIDENTIAL – Covered by ADS Software License Agreement

6. Keep the default value of 1 for the Bestfit Algorithm. If the

Bestfit curve is unacceptable, select 2 from the drop-down list.

Note: Clicking the Use checkbox (off) under Freeflow
points or Backwater points enables you to display either
set of data points on the BestFit curve.

Note: Clicking the Load button enables you to load a
previously generated Bestfit curve. Bestfit coefficient
values must be stored before you can load a Bestfit curve.

Note: Clicking the Store button enables you to store a
Bestfit curve. The Store Data dialog enables you to store
and save the curve with a start date and description.

7. Select OK to generate and display the Bestfit curve.

Using a Previously Saved Bestfit Curve

You can load and use a previously generated and stored Bestfit
curve using the Load option.

Curve
Properties
button

1. Select the View > Curves option or the Curve Properties

toolbar button.

2. Select the Bestfit tab.

3. Select the Load button.

4. Select the previously created Bestfit curve you want to use

from the list.

5. Select OK to load the Bestfit points to the Bestfit tab.

6. Select OK to display the Bestfit curve.
