Profile Main Screen
2-85
CONFIDENTIAL – Covered by ADS Software License Agreement
1998 - 2012 ADS LLC. All Rights Reserved.
containing the pressure coefficients to your local directory
from the ADS website in the following way:
Access the ADS websit
through the
Internet browser on your computer.
Select Environmental Services > Support > Client
Services.
Click on the Download pressure coefficients… link.
Right-click on the year in which the sensor was
manufactured, and select the Save Target As… option.
Rename the file to reflect the following format:
pressure.xx, where xx represents the last two digits of the
year in which the sensor was manufactured. You must
remove the .txt extension!
Save the file to the appropriate location in your local
directory.
• Pipe Height This field displays the pipe height at the
monitor location. This parameter is not editable from this
location in Profile.
• Physical Offset Enter the vertical distance from the bottom
of the pipe to the height at which the pressure depth sensor is
installed in the pipe, provided it is not installed at the bottom
center of the pipe. ADS recommends measuring this during
the monitor/sensor installation or confirmation process.
Profile defaults to 0 inches.
Pipe Maintain an offset of zero (default) if the sensor is
installed at the bottom center of the pipe. If it is installed
up the side of the pipe, enter the vertical distance from the
bottom center of the pipe to the height at which the nose of
the sensor exists. The simplest way to obtain this value is
to measure the depth of the flow, measure the distance
from the nose of the sensor to the flow surface, and then
subtract the second measurement from the first.
Manhole/Wet Well Wall When the sensor is mounted to
the manhole or wet well wall, enter the vertical distance
