4. Enter the depth, silt, and velocity measurements in the following

way, and then select the Next button:

Note: It is essential that you complete the entire form. If the
appropriate depth and velocity measurements are not
available, Profile cannot calculate flow quantity.

 DOF Time Enter the date and time at which the technician

obtained the manual depth measurements.

 Initials of Field Person Performing Manhole Work

Enter the initials of the field technician taking the manual
depth measurements.

 DOF Enter the manually measured distance from the flow

surface to the bottom of the pipe and the estimated accuracy
of the measurement (tolerance or deviation).

 Air DOF Enter the manually measured distance from the

face of the ultrasonic depth sensor or top of the pipe to the
flow surface and any estimated deviation. Select the point of
reference at the top of the pipe from which the technician took
the Air DOF measurement from the corresponding drop-down
list.

The Calculated DOF From Air DOF field displays the flow depth
based on the pipe height, physical offset, and manual air DOF
measurement, compensating for the selected point of reference of the
air DOF (Face of Bat (sensor) or Crown of Pipe).

 DOF Type to Use Select the manual flow depth

measurement (DOF or Air DOF) you want Profile to
compare with the monitor readings.

 Silt Enter the depth of the debris at the bottom of the pipe at

the monitoring point and the estimated accuracy of the
measurement (tolerance or deviation).

 Velocity Enter the velocity of the flow obtained at the

monitoring point manually using a portable velocity meter.

 V-meter No. Enter the serial number of the portable

velocity meter used to obtain the manual measurements.
