ADS Environmental Services Profile Software 950015B6 User Manual

Page 371

7-14

Profile Software User's Guide

CONFIDENTIAL – Covered by ADS Software License Agreement

 Overwriting Existing Data Select this checkbox to

ensure the exported overwrites any duplicate data files
already existing in the export file location. Select the
Warn on Overwrite checkbox to notify you prior to
overwriting any existing data.

 Export Quality Flag Select this checkbox to ensure data

quality flags corresponding to each data point are exported
along with the data. This option is limited to (ADS
Predefined) CSV, Text, and Excel exports.

 Deleting Profile Data After the Export Select this

checkbox to ensure Profile automatically deletes the
exported data from the Profile database following the
export. This option is only available for exporting .IFV
files.

 Span Disks Select this checkbox to ensure Profile

notifies you to insert another disk when the original disk
receiving the export data becomes full. This option is not
available for exporting Excel files.

 Export Quality Value Select this checkbox to ensure

data quality values corresponding to each data point are
exported along with the data. (This option is limited to
(ADS Predefined) CSV, Text, and Excel exports.

Select the OK button to save changes made to the Properties
dialog.

5. Select the monitor locations from the Locations list box and

the corresponding entities from the Available Entities list box
for which you desire to export data.

6. (Optional) Select the appropriate checkboxes in the Import

Other section to import the current configuration file,
calibration log, service log, or final data generator tables
associated with any monitor location selected in the Location
list box.

7. (Optional) Select the Import/Export Only a Specific Span of

Data checkbox and one of the following options to export data
for a user-defined or fixed date and time span:
