Hydrograph Editor

10-15

CONFIDENTIAL – Covered by ADS Software License Agreement

Editing the Hydrograph Data

After successfully setting up your hydrograph, you can begin editing
your data. The editing process includes performing the following
tasks:

• Selecting the data entity you want to edit

• Selecting the hydrograph data you want to edit

• Performing the edits

Selecting the Active Data Entity

When you have more than one data entity displayed on the
hydrograph, you must specify which data entity to apply span edits.
Use the Active Entity drop-down list (located below the toolbar) to
specify the active entity

all span editing modifications will be

performed on the active entity.

Note: Span editing includes all editing except single
point editing.

Selecting Hydrograph Data

After specifying the active data entity, select the hydrograph data
points you want to edit.

Selecting Data Using an Edit Box

Select a graphical span of data by clicking and dragging a selection
box over the data points you want to edit. Once selected, the data
points will display inside a blue outlined area.
