ADS Environmental Services Profile Software 950015B6 - Manual (Page 155)

Profile Main Screen 2-115
CONFIDENTIAL – Covered by ADS Software License Agreement
1998 - 2012 ADS LLC. All Rights Reserved.
Managing the Database Objects
Managing the database objects involves creating new groups to
which you can assign flow monitor and rain gauge locations and
deleting, copying, or pasting objects in the database.
Creating a New Group
Create a new group in the current database using the Group option.
Create a new group and then use the Copy and Paste options to add
monitor locations from the group to the new
group.
1. Select the current database.
New Group
button
2. Select the Edit > New > Group option or the New Group
toolbar button.
A New Group #1 is added to the selected database.
Properties
button
3. Rename the group by highlighting the new group and selecting
the Edit > Properties option or the Properties toolbar button
to display the Group Properties dialog.
Group Properties
4. Enter the new Group Name.
