Profile Main Screen

2-77

CONFIDENTIAL – Covered by ADS Software License Agreement



Usually Dry Pipe typically remains dry, except under wet
weather conditions.

• Electronic Offset Enter the difference that exists between

the depth sensor readings and the manually measured depth.

• Deadband Select the distance from the sensor face within

which readings received will be ignored. The default value
(Auto) represents a percentage of the flow depth and should
be sufficient under normal circumstances. However, consider
another value when the sensor readings reveal a potential
problem with false drop-outs. Choose a value for the
deadband that is sufficiently below the minimum depths that
legitimately occur at the monitoring point, yet above the
confirmed drop-outs that have been detected. For example,
choosing 1 inch causes all ultrasonic depth ranges measured
within 1 inch of the face of the sensor to be ignored.

• Store Data Select this checkbox to ensure the monitor logs

the ultrasonic data to memory. This option is selected by
default.

• Advanced Select this button to access the Advanced

Parameters window.

Note: Modifications made to the Advanced Parameters
should be performed only by or under the guidance of
trained ADS personnel. Therefore, ADS recommends
leaving the default settings in place.

Advanced Parameters
