Diagnostics
6-83
CONFIDENTIAL – Covered by ADS Software License Agreement
1998 - 2012 ADS LLC. All Rights Reserved.
Confirmation Taken Select this checkbox if the field crew
performed confirmations during the site visit.
Debris On Ultrasonic Select this checkbox if the field
crew discovered debris on the ultrasonic depth sensor during
the site visit.
Water in Pressure Hose Select this checkbox if moisture
was detected in the hose extending from the pressure depth
sensor to the monitor.
Evidence Of Surcharge Select this checkbox if
indications exist that a surcharge occurred since the last visit
to the monitor location.
Groundwater Gauge Checked Select this checkbox if
the field crew inspected the groundwater gauge.
Debris On Velocity Select this checkbox if the field crew
discovered debris on the velocity sensor during the site visit.
Velocity Test Confidence Select the best option that
describes the confidence you have in the manual velocity
measurement obtained using the portable velocity meter.
Evidence Of Overflow Select this checkbox if the field
crew discovered evidence that an overflow occurred at the
monitor location since the last site visit.
Overflow Active Select this checkbox if overflow
conditions exist at the monitor location during the site visit.
Chalk Visible Select this checkbox if the chalk line
originally drawn by the field crew inside the overflow is still
present on the channel wall. If an overflow occurs, the flow
typically washes away the chalk line.
Flow Direction Select the direction the flow occurred in the
pipe during the overflow. Forward indicates that the flow
exited the manhole. Reverse indicates that the flow entered
the manhole through the overflow.
The Enter Comments dialog displays.
