Balance Reporter

15-5

CONFIDENTIAL – Covered by ADS Software License Agreement

Verifying the Downstream Monitoring Point
and Time Span

New
button

Select the New toolbar button to access the Monitored Items and
Date Selection tabs. If necessary, use the Monitored Items tab to
change the currently selected downstream monitoring point. Use the
Date Selection tab to change the time span of data displayed on the
balance report.

Creating a Schematic

The Balance Reporter uses information from schematics to
develop flow composites. Developing a schematic includes
identifying the monitoring points located upstream of the current
monitoring point. All flows from upstream monitoring points will
be added to the flow composite; all flows from upstream overflow
monitoring points will be subtracted from the flow composite.

Create a schematic for each monitoring point using one of the
following methods:

• Importing and reviewing QuadraScan schematics

• Using the Profile main screen in order to create and save the

schematic to the Profile database

• Using the Balance Reporter to create a variety of flow

scenarios to check flow balancing

Reviewing Imported QuadraScan Schematics

During QuadraScan data imports, Profile retrieves and stores
schematics to the database. Review imported QuadraScan
schematics for accuracy, and perform updates to the schematics, if
necessary.

1. From the Profile main screen, select the monitoring point you

want to review.
