6-44

Profile Software User's Guide

CONFIDENTIAL – Covered by ADS Software License Agreement

3. Select the appropriate options from the Parameters section to

indicate the type of waveform you want to capture:

 Sensor Select the sensor from which you want to capture a

waveform: Ultrasonic or Velocity.

 Type Select the format of the waveform data you want to

capture.

 MinX Use the default or designate your minimum horizontal

graph scale for displaying the waveform data. This field is
typically used while reviewing a previously created
waveform.

 MaxX Use the default or designate the maximum horizontal

graph scale for displaying the waveform data. This field is
typically used while reviewing a previously created
waveform.

 MinY Use the default or designate the minimum vertical

graph scale for displaying the waveform data. This field is
typically used while reviewing a previously created
waveform.

 MaxY Use the default or designate the maximum vertical

graph scale for displaying the waveform data. This field is
typically used while reviewing a previously created
waveform.

 Details This section is populated with the waveform details

and is used by ADS personnel.

 Waveforms Choose a previously generated waveform to

review from this list when reviewing waveforms offline..

 Visible Subsets Choose a previously generated waveform

subset for the selected waveform during a waveform review.

 Print This section contains the options to print a waveform.

Choose Selected to print all waveform graphs selected from
the Waveforms list. Choose All to print all waveforms from
the Waveforms list or choose Graph to print the current
waveform.
