Hydrograph Editor

10-5

CONFIDENTIAL – Covered by ADS Software License Agreement

Setting Up the Hydrograph Screen

Begin the hydrograph editing process by setting up the hydrograph
screen. The following options are available when setting up the
hydrograph.

Changing the Selected Data Entities

New
button

The New option or toolbar button allows access to the Monitored
Items tab that you can use to change the selected hydrograph data
entities.

Changing the Time Span

New
button

The New option or toolbar button allows access to the Date
Selection tab that you can use to change the selected hydrograph
time span.

Note: The beginning and ending date span default value
will be the last configuration entered.

Adjusting the Hydrograph Scale Values

Adjust the hydrograph scale values manually or automatically.
When three or more entities display on the hydrograph, stacked
graph scales will automatically display.

Manually Setting the Hydrograph Scale

1. Select the scale type to adjust from the Scale Types drop-down

list.
