Adjusting the Scattergraph Scale Values

The Scattergraph Reporter allows you to set the scattergraph
scale values automatically or manually.

Note: Profile automatically will save the minimum and
maximum scales displayed on the scattergraph for the
selected site to the database when you exit Scattergraph
Reporter. Therefore, the next time you bring up that
same site in either Scattergraph or Hydrograph
Reporter, the graph will display based on these scales,
regardless of the date/time range or the method used for
setting the scales.

Automatically Setting the Scattergraph Scale Values

Autoscale
button

Allow Profile to set the scattergraph's scale values automatically
based on the highest and lowest data value during the selected graph
period. Select the View > Autoscale option or the Autoscale
toolbar button and the Scattergraph Reporter will set the scale
values automatically.

Manually Setting the Scattergraph Scale Values

Manually adjust the scattergraph scale values using the Scale Type
drop-down list located under the toolbar.

1. Select the scattergraph scale you want to change from the Scale

Type drop-down list.

2. Enter the new scale minimum and maximum values in the

Minimum Scale and Maximum Scale fields.

The scattergraph scales will adjust according to the new entries.
