Creating Non-Standard Pipe Installations
Create a Non-Standard installation for a monitoring point using the
Create Installation wizard. Provide a response to each wizard
question to successfully develop the new installation.
New
button
1. Access the wizard by selecting the New toolbar button from
the Installation Generator screen.
The Create Installation – Introduction dialog appears.
2. Select the New option and then Next.
3. Select the Pipe option and then the Next button.
4. Select Non-Standard from the Type drop-down list, and select
Next.
5. Enter the Height and Width of the installation, and select
Next.
6. Enter a description as you want it to appear in the Select
Installation drop-down list and select Next.
7. Review the wizard entries in the Summary dialog.
8. Select Finish to complete the wizard or Back to return to a
previous screen to adjust or review an entry.
The Non-Standard dialog appears.
