2. Choose the X axis and Y axis data entities from the X Axis

Dataset and the Left Y Axis Dataset drop-down lists. When a
third scattergraph data entity is displayed, select the Right Y
Axis Dataset.

3. Select OK.

Selecting the Graph Period

Next
Period

Previous
Period

Use this option to view a smaller sub-set of data from a larger time
span. Choose the sub-set amount of data you want to view from the
Graph Period drop-down list. Select the Manual Graph Period
to specify the Start and End dates and times.

Use the Next Period and Previous Period toolbar buttons to move
among multiple pages of the report period.

Changing the Color of the Scattergraph Data

Perform the following steps to change the color assigned to a data
entity displayed on the scattergraph:

Report
Properties
button

1. Select the Report Properties toolbar button to display the

Report Properties dialog.

2. Select the entity you want to change from the Entities list.

3. Select the Color button to display the Color dialog.

4. Choose a new color to represent the data entity.

5. Select the OK button to apply the new color selection.
