12-32 Profile Software User's Guide

CONFIDENTIAL – Covered by ADS Software License Agreement

method in order to select all the data points you want to include.
Selected data will display within a blue box.

Note: If the Inside Tolerance or Outside Tolerance
toolbar buttons are selected, the selection area will include
the entire Y axis.

Clear
Selection
button

Remove a blue selection box by choosing the Clear Selection
toolbar button.

Manually Entering the Data Selection

Graph
Properties
button

Select the View >Graph Properties option or the Graph
Properties toolbar button to manually define a scattergraph data
selection. This method of selecting data is more precise than
dragging a selection box. The Graph Properties screen will
display and allow you to enter a Selection Span. Enter the Min X,
Max X, Min Y, and Max Y graph scale values to define the
selection span. Selected data will display within a blue boxed area.

Removing a Selection Box

Clear
Selection
button

Remove the current selection box by choosing the Clear Selection
toolbar button. For example, when you are finished performing data
edits to a group of selected data points, remove the blue selection
box by choosing the Clear Selection toolbar button.

Editing Scattergraph Data Using Flags

Apply or clear flags to scattergraph data. Flag (or mark) selected
data so that the data no longer affects flow statistics; all flagged data
points are ignored in quantity calculations. Apply flags to any
selected data points when you have reason to believe that a data
point is questionable. The data point can be flagged to be excluded
from calculations and reports.
