Page 458: Displaying confirmation information

Scattergraph Editor

12-25

CONFIDENTIAL – Covered by ADS Software License Agreement

Displaying Scattergraph Information

Profile includes options for displaying field confirmations, pipe
height, silt depth, quality ranges, depth event thresholds, iso-Q



lines, and iso-Froude lines on the scattergraph. Review the
following topics for details on each of these options.

Displaying Field Confirmations

Field confirmations recorded in Profile’s Quantity Coefficient
Generator tool can be displayed on the scattergraph for
informational purposes. Display all or a specific time span of field
confirmations on the scattergraph. Confirmations display on the
scattergraph as diamond symbols: green diamonds indicate included
confirmations, and red diamonds indicate ignored confirmations.

Displaying All Field Confirmations

Confirmation
button

Select the Confirmations toolbar button to display all field
confirmations associated with the current monitor location.

Displaying a Specific Time Span of Field
Confirmations

Confirmations
in Span button

Select the Confirmations in Span toolbar button to display the
field confirmations for the time period specified on the Date
Selection tab (accessed through the New toolbar button).

Displaying Confirmation Information

Anytime field confirmations display on the scattergraph, position
the mouse cursor over the confirmation and click the mouse button
to display the Confirmation Information dialog.
