12-14 Profile Software User's Guide

CONFIDENTIAL – Covered by ADS Software License Agreement

Note: Increasing this value will result in a smoother
curve.

5. In the Max Weight field, use the default value or enter another

weighting value to use for all bins when generating the curve.

Note: The weight of each bin is equal to the number of
points in the bin up to Max Weight.

6. Select OK.

The Setup tab closes.

Generating a Bestfit Curve

Generate a Bestfit scattergraph curve after editing any required
scattergraph data and setting up the curve parameters. The
Scattergraph Editor generates Bestfit curve coefficients after
vertically segmenting the scattergraph into equal parts (bins) and
averaging the data points within each bin to derive the Bestfit curve
points. The default enables you to generate a Bestfit curve
representing freeflow data points and backwater data points. You
also can display either the freeflow set of data points or the
backwater set of data points separately by clicking (off) the
appropriate Use box.

Generate and display a Bestfit curve for the current scattergraph
using the following steps:

Curve
Properties
button

1. Select the Edit > Curve Properties option or the Curve

Properties toolbar button.

2. Select the Bestfit tab.
