10-6 Profile Software User's Guide
CONFIDENTIAL – Covered by ADS Software License Agreement
1998 - 2012 ADS LLC. All Rights Reserved.
2. Enter the new minimum and maximum scale values in the
Minimum Y and Maximum Y fields.
Automatically Setting the Hydrograph Scale
Autoscale
button
Allow Profile to choose the hydrograph's Y axis scale value based
on the highest and lowest data values during the period that appears
on the graph. Select the View > AutoScale option or the AutoScale
toolbar button to allow Profile to set the scales automatically.
Selecting a Hydrograph Format
Select a report format to display the hydrograph data from the Plot
Type drop-down list. Select from Day, Week, Month, Quarter,
Year, or Manual depending on the amount of data you want to
display on a single hydrograph screen. Select from the following
formats:
• Day This option displays the hydrograph data in a 1-day graph
format.
• Week This option displays the hydrograph data in a 7-day
graph format.
• Month This option uses a 31-day graph format.
• Quarter This option displays the hydrograph data in a 92-day
graph format.
• Year This option displays the hydrograph data in a 365-day
graph format.
• Manual This option allows you to specify the beginning and
ending dates and times for the hydrograph report.
