Scattergraph Editor

12-33

CONFIDENTIAL – Covered by ADS Software License Agreement

Setting Data Flags

Apply flags to scattergraph data by performing the following:

1. Select the data to which you want to apply the flags (refer to

Selecting Scattergraph Data, page 12-31).

Flag
button

2. Select the Edit > Flag Data option or the Flag toolbar button

to apply flags to the selected data.

Flagged data will display in red.

Clearing Data Flags

Clear flags from previously flagged data by performing the
following:

1. Select the flagged graph data from which you want to remove

flags (refer to Selecting Scattergraph Data, page 12-31).

Clear
Flags
button

2. Select the Clear Flags toolbar button to clear the flags.

The flags are cleared from the selected data, and the data
points no longer display in red.

Editing Scattergraph Data Using Tolerances

Tolerance ranges, indicated by red lines drawn in parallel above
and/or below a scattergraph curve, reveal acceptable and
unacceptable quality flow data. Data points inside the tolerance
ranges indicate acceptable quality; data points falling outside the
tolerance ranges indicate unacceptable quality. Use the
Scattergraph Editor to establish and display tolerance ranges for
use in editing the data.

Note: You must first generate a scattergraph curve to
enable the checkboxes in the Tolerances section.

Begin by establishing the tolerance ranges. Perform the following
steps to establish the tolerance ranges:
