Quantity Coefficient Generator

4-13

CONFIDENTIAL – Covered by ADS Software License Agreement

Reviewing the Confirmations

After entering the field confirmations to the Quantity Coefficient
Generator, review the confirmations. Determine which
confirmations should be included or ignored in the final coefficient
calculation by reviewing any questionable confirmations on the
confirmation table or in a hydrograph, scattergraph, or tabular view.

Performing a complete review of the confirmations involves the
following activities:

• Specifying the time span of confirmations to include in the

hydrograph or scattergraph

• Displaying the pipe height and silt depth on the selected graph

• Reviewing the confirmations and coefficients in the table

• Reviewing the confirmations on a hydrograph

• Reviewing the confirmations on a scattergraph

Specifying the Time Span

New
button

Use the Date Selection tab to specify the beginning and ending
dates for the time period of confirmations you want to review in a
hydrograph or scattergraph. Select the File > New option or the
New toolbar button to access the Date Selection tab. Select a Fixed
Time Span or enter a User-Defined Time Span.

Displaying Pipe Height and Silt Depth on a
Graph

Display the pipe height and silt depth for the current monitoring
point on the scattergraph or hydrograph by selecting the View >
Plot Pipe Height and/or the View > Plot Silt options. The pipe
