6 Appendix
PC Control / Touch Control
305
6 Appendix
In this section you will find the most important technical data for the
Touch Control, a list of standard accessories and optional accessories
for the Touch Control and PC Control software as well as the warranty
and declarations of conformity.
6.1 Technical data
Provided that nothing to the contrary is mentioned, the published val-
ues represent typical technical data for the Touch Control.
6.1.1 Touch screen
Display ¼ VGA color display, 320 pixel x 240 pixel,
12 cm x 9 cm
Touch panel analog resistive
6.1.2 Interfaces
Titrando connection
Cable 8-pole, 70 cm, shielded, Mini-DIN plug with lock
PCMCIA card slot
Card slot PCMCIA (Personal Computer Memory Card Interna-
tional Association)
ATA Card type I/II
Cards FlashCards for storing methods, determinations, sam-
ple data silos, result silos and backups
(PCMCIA cards or CompactFlash cards with Compact-
Flash adapter)
6.1.3 Power supply
Voltage
Power consumption
Batteries
±12 V, +5 V
5 W
2 x 1.5 V alkaline manganese or lithium, type
LR6/AA/AM3
6.1.4 Safety specifications
Construction and testing According to EN/IEC/UL 61010-1, CSA-C22.2 No.
61010-1, protection class III
Safety information The documentation contains safety instructions which
have to be followed by the user in order to ensure safe
operation of the instrument.
