3 Operation
PC Control / Touch Control
149
list or entered directly. You can also send the sample size from a
connected balance (see Section 3.10.8). If you have defined a sample
size unit (see Section 3.16.6) then this will be ignored in the sample
data silo. The sample size unit entered in the sample data silo will
always be used. If you have defined a fixed sample size (see
Section 3.16.6) then this will be written into the corresponding silo line
when the method is opened. The previously entered sample size (this is
usually still the default value of 1.00 g) will be overwritten.
You can also define sample size limits in the method; these will be
monitored in the determination sequence (see Section 3.16.6).
Note!
The sample size limits are not monitored during the input of the
sample data in the sample data silo.
Properties of the sample data silo
Open the dialog Sample data silo/Properties. With PC Control
this is done by selecting the menu item Properties under Action
(see p 146). With Touch Control open the corresponding dialog
from the sample data silo table with [Properties].
The details of the dialogs [Display options], [Edit options] and
[Identifications] are described on the following pages.
Attention!
With PC Control the settings made under Sample data
silo/Properties and its subdialogs will only become effective when
the dialog is changed, e. g. with [Back].
Under Method memory select the memory location from which the
methods for carrying out the determinations are to be loaded.
Touch Control: choose whether Identification 1 or 2 and the
sample size or only the method is to be shown in the silo table.
With PC Control all the columns are always shown.
You can enter the maximum Number of silo lines. When this
number of lines has been entered the silo is full and no further lines
can be added.
