Chapter 36: Management Access Control List
Section VII: Management Security 712
Creating a Management ACL
To create a Management ACL, perform the following procedure:
1. From the Main Menu, type 5 to select System Administration.
The System Administration menu is shown in Figure 7 on page 55.
2. From the System Administration menu, type 7 to select Management
ACL.
The Management ACL menu is shown in Figure 249.
Figure 249 Management ACL Menu
Note
Do not activate this feature until you have specified the ACEs.
Otherwise, the unit will discard all remote management packets,
making it impossible for you to remotely manage the switch from a
Telnet or web browser management session.
3. Type 2 to select Add Management ACL Entry.
The following prompt is displayed:
Enter the IP address:
4. Enter the IP address of a specific management workstation (for
example, 149.11.11.11) or a subnet (for example, 149.11.11.0). You
must enter an IP address.
The following prompt is displayed:
Enter the Mask:
5. Enter a mask that indicates the parts of the IP address the switch
should filter on. A binary “1” indicates the switch should filter on the
corresponding bit of the address, while a “0” indicates that it should
not. If you are filtering on a specific IP address, use the mask
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2004
Management ACL Menu
Configuring Management ACL
1 - Management ACL Status ........... Disabled
2 - Add Management ACL Entry
3 - Delete Management ACL Entry
4 - Display all Management ACL Entries
R - Return to Previous Menu
Enter your selection?
