Chapter 8: Port Trunking
Section I: Basic Operations 140
The LACP (IEEE 8023ad) Configuration menu is shown in Figure 39.
Figure 39 LACP (IEEE 8023ad) Configuration Menu
4. Type 1 to toggle LACP Status between Disabled and Enabled. The
default is disabled.
5. After making changes, type R until you return to the Main Menu. Then
type S to select Save Configuration Changes.
Setting a LACP
System Priority
This procedure explains how to set the LACP system priority value on a
switch. The switch uses this parameter if a conflict occurs when
establishing an aggregate trunk with the other device. The LACP
settings on the device with the higher priority take precedence over the
settings on the other device. The lower the value, the higher the priority.
A switch can have only one LACP system priority. For more information,
refer to LACP System Priority on page 127.
To set the LACP system priority for the switch, perform the following
procedure:
1. From the Main Menu, type 1 to select Port Configuration.
2. From the Port Configuration menu, type 4 to select Port Trunking and
LACP.
The Port Trunking and LACP menu is shown in Figure 36 on page 134.
3. Type 2 to select LACP Configuration.
The LACP (IEEE 8023ad) Configuration menu is shown in Figure 39 on
page 140.
4. Type 2 to s elect Priority.
The following prompt is displayed:
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2004
LACP (IEEE 802.3ad) Configuration
1 - LACP Status ....................... Disabled
2 - Priority .......................... 0x0080
3 - Create Aggregator
4 - Modify Aggregator
5 - Configure Port
6 - Delete Aggregator
7 - Show LACP Port Status
8 - Show LACP Aggregator Status
R - Return to Previous Menu
Enter your selection?
