Chapter 20: Power Over Ethernet
Section II: Advanced Operations 330
Power Status
Whether power is being supplied to the device. ON means that
the port is providing power to a powered device. OFF means the
device is not a powered device or PoE has been disabled on the
port.
3 - Detailed Ports Status Menu
When you select this option, you are prompted to enter the
port(s) you want to view. You can specify more than one port at a
time. Once you have specified the port, the selection displays the
following window:
Figure 116 PoE Summary Ports Status Menu
The selections in this window are for viewing purposes only. Each
selection is described below.
Port
Port number.
PoE Function
Whether PoE is enabled or disabled on the port. The default
setting is enabled. To enable or disable PoE on a port, refer to
Configuring PoE Port Settings on page 325.
Allied Telesyn Ethernet Switch AT-8524POE - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2004
PoE Detailed Port Status
Port: 4
PoE Function ........... ENABLED
Power Status ........... ON - Valid PD detected
Power Consumed ......... 1,900 mW
Power Limit ............ 15,400 mW
Power Priority ......... Low
Power Class ............ 1
Voltage ................ 48.6V
Current ................ 40 mA
U - Update Display
R - Return to Previous Menu
Enter your selection?
