AT-S62 Menus Interface User’s Guide
Section IV: Spanning Tree Protocols 509
The following prompt is displayed:
Start port to configure: [1 to 26] -> 1
4. Enter the number of the port you want to configure. To configure a
range of ports, enter the first port of the range.
The following prompt is displayed:
End port to configure: [1 to 26] -> 1
5. Enter the last port of the range. To configure just one port, enter the
same port here as in Step 3.
Configure Per Spanning Tree Port Settings Menu is shown in
Figure 178.
Figure 178 Configure Per Spanning Tree Port Settings Menu
The Spanning Tree List displays the ID numbers of the MSTIs you
specified.
6. Adjust the port settings as needed. The selections are described
below:
1 - Port Priority
This parameter is used as a tie breaker when two or more ports are
determined to have equal costs to the regional root bridge. The
range is 0 to 240 in increments of 16. The default value is 8 (priority
value 128). For a list of the increments, refer to Table 15, Port
Priority Value Increments on page 460.
2- Port Internal Path Cost
The port cost of the port if the port is connected to a bridge which
is part of the same MSTP region. The range is 0 to 200,000,000. The
default setting is Auto-detect, which sets port cost depending on
the speed of the port. Table 18 lists the MSTP port costs with Auto
Update.
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2004
Configure Per Spanning Tree Port Settings
Spanning Tree List: 4
Configuring Ports: 7-7
1 - Port Priority ............... 128
2 - Port Internal Path Cost ..... Auto Update
R - Return to Previous Menu
Enter your selection?
