Chapter 13: Event Log
Section II: Advanced Operations 204
The Event Log menu is shown in Figure 60.
Figure 60 Event Log Menu
3. Type 1 to toggle Log Status between the two selections Enabled and
Disabled. If you enable the log, the switch immediately begins to add
events in the log and send events to defined syslog servers. The
default is enabled.
The other options in this menu are used to display the contents of
the event log. For instructions, refer to Displaying the Event Log
on page 204.
4. After making changes, type R until you return to the Main Menu. Then
type S to select Save Configuration Changes.
To display the events in the log, go to the next procedure. To
configure the switch for a syslog server, refer to Managing Syslog
Server Definitions on page 211.
Displaying the
Event Log
This procedure explains how to view the event log from your local or
remote management session. To view the event log, do the following:
1. From the Main Menu, type 5 to select System Administration.
2. From the System Administration menu, type 8 to select Event Log.
The Event Log menu is shown in Figure 60 on page 204.
3. Configure options 2 through 6 in the Event Log menu to specify the
types of events you want to view. The options are described below:
2 - Display Output
Selects an event log. This option has only one selection,
Temporary. The event log is located in temporary memory.
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2004
Event Log
1 - Event Logging..............Enabled
2 - Display Output.............Temporary (Memory)
3 - Display Order..............Chronological
4 - Display Mode...............Normal
5 - Display Severity...........E,W,I
6 - Display Module.............All
C - Clear Log
L - Configure Log Outputs
S - Save Log to File
V - View Log
R - Return to Previous Menu
Enter your selection?
