Chapter 16: Quality of Service
Section II: Advanced Operations 276
The Create Traffic Class menu is shown in Figure 92.
Figure 92 Create Traffic Class Menu
5. Configure the parameters as needed. The parameters are described
below:
1 - Traffic Class ID
Specifies an ID number for the traffic class. Each traffic class on the
switch must be assigned a unique number. The range is 0 to 511.
The default is 0. This parameter is required.
2 - Description
Specifies a description for the traffic class. The description can be
from 1 to 15 alphanumeric characters. Spaces are allowed. This
parameter is optional, but recommended. Names can help you
identify the traffic classes on the switch.
3 - Exceed Action
Specifies the action to be taken if the traffic of the traffic class
exceeds the maximum bandwidth, specified in option 6. There are
two possible exceed actions, drop and remark. If drop is selected,
traffic exceeding the bandwidth is discarded. If remark is selected,
the packets are forwarded after replacing the DSCP value with the
new value specified in option 4, Exceed Remark Value. The default
is drop.
4 - Exceed Remark Value
Specifies the DSCP replacement value for traffic that exceeds the
maximum bandwidth. This value takes precedence over the DSCP
value set with option 5, DSCP Value. The default is 0.
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2004
Create Traffic Class
1 - Traffic Class ID .......... 0
2 - Description ...............
3 - Exceed Action ............. Drop
4 - Exceed Remark Value ....... 0
5 - DSCP value ................
6 - Max bandwidth .............
7 - Burst Size ................
8 - Priority ..................
9 - Remark Priority .......... No
A - Flow Group List ...........
C - Create Flow Group
R - Return to Previous Menu
Enter your selection?
