Untagged (U) / Tagged (T) - The ports of the VLAN. Tagged ports are
designated with a “T” and untagged ports with a “U.”
3. To view additional information about a protected ports VLAN, type D
to select Detail Information Display.
The following prompt is displayed:
Enter new value ->
4. Enter the VID of the protected ports VLAN whose information you
want to view.
An example of the Show VLANs window for a protect ports VLAN is
shown in Figure 209.
Figure 209 Show VLANs Menu
Section 1 lists all the tagged and untagged ports in the protected
ports VLAN.
Section 2 lists each group in the VLAN, starting with the uplink port(s).
The groups are listed by group number followed by the port
numbers. For example, in Figure 209 the uplink port for the VLAN is
port 25 and Group 1 consists of ports 12 and 13.
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2004
Show VLANs
VID VLAN Name VLAN Type Protocol Untagged (U) / Tagged (T)
---------------------------------------------------------------
5 Internet_VLAN Protected U: 12-24
Protected T: 25
Group Ports
------------------------------------------
Uplink
25
1 12-13
2 14-15
3 16
4 17
5 18-20
N - Next Page
U - Update Display
R - Return to Previous Menu
Enter your selection?
Section 1
Section 2
