Chapter 25: Tagged and Port-based Virtual LANs
Section V: Virtual LANs 538
Displaying VLANs
To view the name, VID number, and member ports of all the VLANs on a
switch, perform the following procedure:
1. From the Main Menu, type 2 to select VLAN Configuration.
The VLAN Configuration menu is shown in Figure 182 on page 528.
2. From the VLAN Configuration menu, type 5 to select Show VLANs.
An example of the Show VLANs menu is shown in Figure 187.
Figure 187 Show VLANs Menu
The menu contains the following columns of information:
VID - The VLAN ID.
VLAN Name - The name of the VLAN.
VLAN Type - A VLAN type of “Port Based” indicates a port-based or
tagged VLAN. A VLAN type of “GARP” indicates a VLAN created
automatically by GVRP. A VLAN type of “Protected” indicates a
protected ports VLAN.
Protocol - If this column is blank, the VLAN is a port-based, tagged, or
protected ports VLAN. If it contains “GARP,” the VLAN or the port is a
dynamic GVRP VLAN or a dynamic GVRP port of a static VLAN.
Untagged (U) / Tagged (T) - The ports of the VLAN. Tagged ports are
designated with a “T” and untagged ports with a “U.”
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
Show VLANs
User: Manager 11:20:02 02-Jan-2004
VID VLAN Name VLAN Type Protocol Untagged (U) / Tagged (T)
----------------------------------------------------------------
1 Default_VLAN Port Based U: 20-24
T: 7,9
2 Sales Port Based U: 1-7
T: 9
3 Production Port Based U: 8-19
T: 7
N - Next Page
U - Update Display
R - Return to Previous Menu
Enter your selection?
