Chapter 18: IGMP Snooping
Section II: Advanced Operations 306
Displaying a List of Host Nodes
To view a list of the multicast groups and host nodes on a switch,
perform the following procedure:
1. From the Main Menu, type 6 to select Advanced Configuration.
The Advanced Configuration menu is shown in Figure 103 on page
303.
2. From the Advanced Configuration menu, type 1 to select IGMP
Snooping Configuration.
The IGMP Snooping Configuration menu is shown in Figure 104 on
page 303.
3. From the IGMP Snooping Configuration menu, type 6 to select View
Multicast Host List.
The View Multicast Host List is shown in Figure 105.
Figure 105 View Multicast Hosts List Menu
The information in this menu is for viewing purposes only. The
columns are defined below:
Multicast Group - The multicast address of the group.
VLAN ID - The VID of the VLAN where the port is an untagged
member.
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2004
View Multicast Hosts List
Number of Multicast Groups: 4
VLAN Port/ IGMP Exp.
MulticastGroup ID TrunkID HostIP Ver Time
------------------------------------------------------------
01:00:5E:00:01:01 1 6/- 172.16.10.51 v2 21
01:00:5E:7F:FF:FA 1 5/- 149.35.200.75 v2 11
01:00:5E:00:00:02 1 17/- 149.35.200.69 v2 34
01:00:5E:00:00:09 1 14/- 172.16.10.51 v2 32
U - Update Display
R - Return to Previous Menu
Enter your selection?
