Chapter 16: Quality of Service
Section II: Advanced Operations 264
Video Applications
Video applications typically require a larger bandwidth than voice
applications. Video applications can be set up to have a high priority and
buffering, depending on the application.
This example creates policies with low latency and jitter for video
streams (for example, net conference calls). The policies in Figure 84
assign the packets a priority level of 4 and limit the bandwidth to 5
Mbps. The node containing the application has the IP address
149.44.44.44. Policy 17 is assigned to port 1, where the application is
located, and Policy 32 is assigned to port 8 where packets destined to
the application enter the switch.
Figure 84 QoS Video Application Example
Create Classifier
01 - Classifier ID: ..... 16
02 - Desciption ......... Video flow
.
.
12 - Src IP Addr ....... 149.44.44.44
13 - Src IP Mask .......
Create Flow Group
1 - Flow Group ID ............. 41
2 - Description ................... Video
3 - DSCP Value .................
4 - Priority ......................... 4
5 - Remark Priority ........... No
6 - Classifier List .............. 16
Create Traffic Class
1 - Traffic Class ID: ........ 19
2 - Desciption ................ Video
.
.
6 - Max Bandwidth ........ 5
.
.
A - Flow Group List ....... 41
Create Policy
1 - Policy ID: ................ 17
2 - Desciption .............. Video flow
.
.
5 - Traffic Class List ....... 19
6 - Ingress Port List ....... 1
Create Classifier
01 - Classifier ID: ..... 42
02 - Desciption ......... Video flow
.
.
12 - Dst IP Addr ........ 149.44.44.44
13 - Dst IP Mask .......
Create Flow Group
1 - Flow Group ID ............. 36
2 - Description ................... Video
3 - DSCP Value .................
4 - Priority ......................... 4
5 - Remark Priority ........... No
6 - Classifier List .............. 42
Create Traffic Class
1 - Traffic Class ID: ........ 21
2 - Desciption ................ Video
.
.
6 - Max Bandwidth ........ 5
.
.
A - Flow Group List ....... 36
Create Policy
1 - Policy ID: ................ 32
2 - Desciption .............. Video flow
.
.
5 - Traffic Class List ....... 21
6 - Ingress Port List ....... 8
Policy 17 Policy 32
