AT-S62 Menus Interface User’s Guide
Section II: Advanced Operations 269
Managing Flow Groups
This section contains the following procedures:
❑ Creating a Flow Group on page 269
❑ Modifying a Flow Group on page 271
❑ Deleting a Flow Group on page 272
❑ Displaying Flow Groups on page 273
Creating a Flow
Group
To create a flow group, perform the following procedure:
1. From the Main Menu, type 7 to select Security and Services.
2. From the Security and Services menu, type 6 to select Quality of
Service.
The Quality of Service (QoS) menu is shown in Figure 87.
Figure 87 Quality of Service (QoS) menu
3. From the Quality of Service (QoS) menu, type 1 to select Flow Group
Configuration.
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2004
Quality of Service (QoS)
1 - Flow Group Configuration
2 - Traffic Class Configuration
3 - Policy Configuration
R - Return to Previous Menu
Enter your selection?
