AT-S62 Menus Interface User’s Guide
Section I: Basic Operations 135
The Create Trunk menu is shown in Figure 37.
Figure 37 Create Trunk Menu
5. Type 1 to select Trunk ID and, when prompted, enter an ID number
for the trunk of from 1 to 6. A trunk must be assigned a unique ID
number. The default value is the next unused ID number.
6. Type 2 to select Trunk Name and, when prompted, enter a name for
the trunk. The name can be up to sixteen alphanumeric characters.
No spaces or special characters, such as asterisks and exclamation
points, are allowed. Each trunk must have a unique name.
7. To set the load distribution method, type 3 to toggle the selection
through the following possible settings:
❑ SRC MAC - Source MAC address
❑ DST MAC - Destination MAC address
❑ SRC/DST MAC - Source address /destination MAC address
❑ SRC IP - Source IP address trunking
❑ DST IP - Destination IP address trunking
❑ SRC/DST IP - Source address /destination IP address
The default is SRC/DST MAC. For background information, refer to
Load Distribution Methods on page 130.
8. Type 4 to select Trunk Ports and, when prompted, enter the ports of
the trunk. A trunk can contain up to eight ports. You can identify the
ports individually (for example, 3,7,10), as a range (for example, 5-11),
or both (for example, 2,4,11-14).
9. Type C to select Create Trunk.
The port trunk is now active on the switch.
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2004
Create Trunk
1 - Trunk ID ......... 1
2 - Trunk Name .......
3 - Trunk Method ..... SRC/DST MAC
4 - Trunk Ports ......
C - Create Trunk
R - Return to Previous Menu
Enter your selection?
