Chapter 7: MAC Address Table
Section I: Basic Operations 112
3. Select the desired option. The options are explained below:
1 - Display All
This selection displays all dynamic addresses learned on the ports
of the switch and all static addresses that have been assigned to
the ports. An example of a unicast MAC address table is shown in
Figure 29.
Figure 29 Display All Menu - Unicast MAC Addresses
Note
The first address in the unicast MAC address table is the address of
the switch.
The information in this menu is for viewing purposes only. The
columns in a unicast MAC address menu are defined below.
MAC - The static or dynamic unicast MAC address.
Port - The port where the address was learned or assigned. The
MAC address with Port 0 is the address of the switch.
VlanID - The ID number of the VLAN where the port is an
untagged member.
Type - The type of the address: static or dynamic.
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2004
Display All
Page 1
Total Number of MAC Addresses: 121
MAC Address Port VlanID Type
---------------------------------------------------------------------
01:80:C1:00:02:01
0 0 Static (fixed, non-aging)
00:a0:d2:18:1a:c8 1 1 Dynamic
00:a0:c4:16:3b:80 2 1 Dynamic
00:a0:12:c2:10:c6 3 1 Dynamic
00:a0:c2:09:10:d8 4 1 Dynamic
00:a0:33:43:a1:87 5 1 Dynamic
00:a0:12:a7:14:68 6 1 Dynamic
00:a0:d2:22:15:10 7 1 Dynamic
00:a0:d4:18:a6:89 8 1 Dynamic
N - Next Page
U - Update Display
R - Return to Previous Menu
Enter your selection?
