AT-S62 Menus Interface User’s Guide
Section V: Virtual LANs 543
Displaying PVIDs and Port Priorities
The following procedure displays a menu that lists the PVIDs for all the
ports on the switch. The menu also contains the current priority queue
settings for each port. To display the PVID settings on the switch,
perform the following procedure:
1. From the Main Menu, type 2 to select VLAN Configuration.
The VLAN Configuration menu is shown in Figure 182 on page 528.
2. From the VLAN Configuration menu, type 6 to select Show PVIDs.
The Show PVIDs menu is shown in Figure 190.
Figure 190 Show PVIDs & Priorities Menu
The PVID column displays the current PVID value for each switch port.
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2004
Show PVIDs
Port PVID
---------------
01 1
02 1
03 1
04 1
05 1
06 1
07 1
N - Next Page
U - Update Display
R - Return to Previous Menu
Enter your selection?
