AT-S62 Menus Interface User’s Guide
Section II: Advanced Operations 275
Managing Traffic Classes
This section contains the following procedures:
❑ Creating a Traffic Class on page 275
❑ Modifying a Traffic Class on page 279
❑ Deleting a Traffic Class on page 280
❑ Displaying Traffic Classes on page 280
Creating a Traffic
Class
To create a traffic class, perform the following procedure:
1. From the Main Menu, type 7 to select Security and Services.
2. From the Security and Services menu, type 6 to select Quality of
Service.
The Quality of Service (QoS) menu is shown in Figure 87 on page
269.
3. Type 2 to select Traffic Class Configuration.
The Traffic Class Configuration menu is shown in Figure 91.
Figure 91 Traffic Class Configuration Menu
4. Type 1 to select Create Traffic Class.
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2004
Traffic Class Configuration
1 - Create Traffic Class
2 - Modify Traffic Class
3 - Destroy Traffic Class
4 - Show Traffic Classes
R - Return to Previous Menu
Enter your selection?
