AT-S62 Menus Interface User’s Guide
Section V: Virtual LANs 589
3. From the Configure VLANs Menu, type 2 to select Modify VLAN.
The Modify VLAN Menu is shown in Figure 185 on page 534.
4. Type 1 to select VLAN ID (VID).
The following prompt is displayed:
Enter new value -> [1 to 4096] ->
5. Enter the VID of the VLAN you want to modify.
The Modify VLAN Menu expands to contain all relevant information
about the VLAN, as shown in Figure 207.
Figure 207 Expanded Modify VLAN Menu
6. Adjust the following parameters as necessary.
1 - VLAN Name
Use this selection to change the name of a VLAN. The name can be
from one to fifteen alphanumeric characters in length. The name
cannot contain spaces or special characters, such as asterisks (*) or
exclamation points (!).
When you change a VLAN’s name, observe the following guidelines:
❑ A VLAN’s new name cannot be the same as the name of another
VLAN on the same switch.
❑ You cannot change the name of the Default_VLAN.
Note
A VLAN must have a name.
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2004
Modify VLAN
1 - VLAN Name .............. Internet_1
2 - VLAN ID (VID) .......... 3
3 - Tagged Ports ........... 7,9
4 - Untagged Ports ......... 20-24
5 - Protected Ports ........ Yes
M - Modify VLAN
R - Return to Previous Menu
Enter your selection?
