AT-S62 Menus Interface User’s Guide
Section V: Virtual LANs 529
The Configure VLANs menu is shown in Figure 183.
Figure 183 Configure VLANs Menu
3. From the Configure VLANs menu, type 1 to select Create VLAN.
The Create VLAN menu is shown in Figure 184.
Figure 184 Create VLAN Menu
4. Type 1 to select VLAN Name and enter a name for the new VLAN.
The name can be from one to twenty alphanumeric characters in
length. The name should reflect the function of the nodes that will be
a part of the VLAN (for example, Sales or Accounting). The name
cannot contain spaces or special characters, such as asterisks (*) or
exclamation points (!).
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2004
Configure VLANs
1 - Create VLAN
2 - Modify VLAN
3 - Delete VLAN
4 - Reset to Default VLAN
R - Return to Previous Menu
Enter your selection?
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2004
Create VLAN
1 - VLAN Name ............
2 - VLAN ID (VID) ........ 2
3 - Tagged Ports .........
4 - Untagged Ports .......
5 - Protected Ports ...... No
C - Create VLAN
R - Return to Previous Menu
Enter your selection?
