To deny traffic from several subnets on the same port, you can create
multiple classifiers and apply them to the same ACL. This example
denies traffic on port 4 from three subnets using three classifiers, one for
each subnet, assigned to the same ACL.
Figure 72 ACL Example 2
Create Access Control Lists (ACL)
1 - ACL ID ................. 4
2 - Description .......... Subnets - deny
3 - Action .................. Deny
4 - Classifier List ...... 22, 24, 62
5 - Port List .............. 4
Create Classifier
01 - Classifier ID: ..... 24
02 - Description: ...... 149.22.22 flow
.
.
12 - Src IP Addr: ..... 149.22.22.0
13 - Src IP Mask: .... 255.255.255.0
Create Classifier
01 - Classifier ID: ..... 22
02 - Description: ...... 149.11.11 flow
.
.
12 - Src IP Addr: ..... 149.11.11.0
13 - Src IP Mask: .... 255.255.255.0
Create Classifier
01 - Classifier ID: ..... 62
02 - Description: ...... 149.33.33 flow
.
.
12 - Src IP Addr: ..... 149.33.33.0
13 - Src IP Mask: .... 255.255.255.0
