Chapter 25: Tagged and Port-based Virtual LANs
Section V: Virtual LANs 536
3 - Tagged Ports
Use this selection to add or remove tagged ports from the VLAN. You
can specify the ports individually (e.g., 2,3,5), as a range (e.g., 7-9), or
both (e.g., 2,5,7-9).
When adding or removing tagged ports, observe the following
guidelines:
❑ The new list of tagged ports will replace the existing tagged ports.
❑ If the VLAN contains tagged ports and you want to remove them
all, enter 0 (zero) for this value.
4 - Untagged Ports
Use this selection to add or remove untagged ports from the VLAN.
You can specify the ports individually (e.g., 2,3,5), as a range (e.g., 7-9),
or both (e.g., 2,5,7-9).
When adding or removing untagged ports, observe the following
guidelines:
❑ The new list of untagged ports will replace the existing untagged
ports.
❑ If you want to remove all untagged ports from the VLAN, enter 0
(zero) for this value.
❑ You cannot change the name of the Default_VLAN, nor can you
directly remove untagged ports from the Default_VLAN. Instead,
you must assign the port as an untagged port to another VLAN.
An untagged port removed from a VLAN is automatically returned to
the Default_VLAN as an untagged port.
Note
Option 5, Protected Ports, in the Modify VLAN menu is not used to
modify port-based and tagged VLANs. It should be left in the “No”
default setting. This option is used to modify protected ports VLANs,
as explained in Chapter 28, Protected Ports VLANs on page 581.
7. After making the desired changes, type M to select Modify VLAN.
The following message is displayed:
SUCCESS
Please make sure to manually update any static
multicast MAC address(es) entries for this VLAN.
Press any key to continue...
The VLAN has been modified and is now ready for network
operations.
