AT-S62 Menus Interface User’s Guide
Section II: Advanced Operations 247
Modifying an ACL
This procedure explains how to modify an ACL. In order to perform this
procedure, you need to know the ID number of the ACL you want to
modify. To display ACL ID numbers, refer to Displaying ACLs on page
252. If you plan to add classifiers to the ACL, you also need to know the
ID numbers of the classifiers. To view classifier ID numbers, refer to
Displaying Classifiers on page 235.
To modify an ACL, perform the following procedure:
1. From the Main Menu, type 7 to select Security and Services.
2. From the Security and Services menu, type 4 to select Access Control
Lists.
The Access Control Lists (ACL) menu is shown in Figure 77 on page
245.
3. From the Access Control Lists (ACL) menu, type 2 to selection Modify
ACL.
The following prompt is displayed:
Available ACL(s): 0-15
Enter ACL ID : [0 to 255] -> 0
4. Enter the ID number of the ACL you want to modify. You can modify
only one ACL at a time.
The Modify ACL window is displayed with the specifications of the
selected ACL. An example of the window is shown in Figure 79.
Figure 79 Modify ACL Menu
You cannot change an ACL’s ID number.
Allied Telesyn Ethernet Switch AT-8524M - ATS62
Production Switch
User: Manager 11:20:02 02-Jan-2004
Modify ACL
1 - ACL ID ............ 12
2 - Description ....... HTTP - permit
3 - Action ............ Permit
4 - Classifier List ... 18,22
5 - Port List ......... 7,10-14
M - Modify ACL
R - Return to Previous Menu
Enter your selection?
