AT-S62 Menus Interface User’s Guide
Section II: Advanced Operations 295
Note
Options 7, 8, and 9 are not available in all versions of the AT-S62
management software. Contact your sales representative to
determine if these features are available for your locale.
2. From the Security and Services menu, type 5 to select Class of Service
(CoS).
The Class of Service (CoS) menu is shown in Figure 98.
Figure 98 Class of Service (CoS) Menu
The “Number of CoS Queues” line indicates the number of egress
queues each port has. On the AT-8500 Series switch, there are four
queues per port. This value cannot be changed.
3. From the Class of Service menu, type 1 to select Configure Port CoS
Priorities.
The following prompt is displayed:
Enter port number -> [1 to 26] ->
4. Enter the number of the port on the switch where you want to
configure CoS. You can specify only one port at a time.
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2004
Class of Service (CoS)
Number of CoS Queues: 4
1 - Configure Port CoS Priorities
2 - Map CoS Priority to Egress Queue
3 - Configure Egress Scheduling
4 - Show Port CoS Priorities
R - Return to Previous Menu
Enter your selection?
