Chapter 28: Protected Ports VLANs
Section V: Virtual LANs 594
Deleting a Protected Ports VLAN
All untagged ports in a deleted protected ports VLAN are automatically
returned to the Default_VLAN.
To delete a protected ports VLAN, perform the following procedure:
1. From the Main Menu, type 2 to select VLAN Configuration.
The VLAN Configuration Menu is shown in Figure 182 on page 528.
2. From the VLAN Configuration Menu, type 4 to select Configure
VLANs.
The Configure VLANs Menu is shown in Figure 183 on page 529.
Note
If option 4, Configure VLANs, is not displayed in the menu if the
switch is running a multiple VLAN mode. To change a switch’s VLAN
mode, refer to Selecting a VLAN Mode on page 579.
3. From the Configure VLANs Menu, type 3 to select Delete VLAN.
The Delete VLAN Menu is shown in Figure 210.
Figure 210 Delete VLAN Menu
4. Type 1 to select VLAN ID (VID).
The following prompt is displayed:
Enter new value -> [2 to 4094] ->
5. Enter the VID of the VLAN you want to delete. You can specify only
one VID at a time.
Note
You cannot delete the Default_VLAN, which has a VID of 1.
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2004
Delete VLAN
1 - VLAN ID (VID) ........
R - Return to Previous Menu
Enter your selection?
