AT-S62 Menus Interface User’s Guide
Section VI: Port Security 605
Displaying Port Security Levels
To view the current security levels for the ports on the switch, do the
following:
1. From the Main Menu, type 1 to select Port Configuration.
2. From the Port Configuration menu, type 5 to select Port Security.
The Port Security menu is shown in Figure 212 on page 602.
3. From the Port Security menu, type 2 to select Display Port Security.
The Display Port Security menu is shown in Figure 215.
Figure 215 Display Port Security Menu
This menu is for viewing purposes only. The columns in the menu
are defined below:
Port
The number of the port.
Security Mode
The active security mode on the port.
Threshold
This column specifies the maximum number of dynamic MAC
addresses the port will learn. It only applies when a port is
operating in the Limited security mode.
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2004
Display Port Security
Port Security Mode Threshold Intruder Action Participating
----------------------------------------------------------------
1
Limited 6 Trap Yes
2 Limited 10 Trap Yes
3 Automatic --- ------ ---
4 Locked --- Discard No
5 Automatic --- ------ ---
6 Automatic --- ------ ---
7 Automatic --- ------ ---
8 Secured --- Discard No
N - Next Page
U - Update Display
R - Return to Previous Menu
Enter your selection?
