Chapter 8: Port Trunking
Section I: Basic Operations 144
To modify an aggregator, perform the following procedure:
1. From the Main Menu, type 1 to select Port Configuration.
2. From the Port Configuration menu, type 4 to select Port Trunking and
LACP.
The Port Trunking and LACP menu is shown in Figure 36 on page 134.
3. Type 2 to select LACP Configuration.
The LACP (IEEE 8023ad) Configuration menu is shown in Figure 39 on
page 140.
4. Type 4 to select Modify Aggregator.
The Modify LACP (IEEE 8023ad) Aggregator menu is shown in Figure
41.
Figure 41 Modify LACP (IEEE 8023ad) Aggregator Menu
5. Type 1 to select Aggregator or 2 for Adminkey and, when prompted,
enter the name or adminkey of the aggregator you want to modify.
You can specify the aggregator by its name or adminkey number. The
name is case-sensitive.
After you enter the aggregator’s name or adminkey, the
specifications of the aggregator are displayed in the menu.
6. Adjust the settings as necessary. The parameters are defined here:
1 - Aggregator
Specifies a name for the aggregator. The name can be up to twenty
alphanumeric characters. Spaces are allowed, but special characters,
such as asterisks and exclamation points, are not. Each aggregator
must have a unique name.
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2004
Modify LACP (IEEE 802.3ad) Aggregator
1 - Aggregator ..................
2 - Adminkey .................... 0x0000
3 - Distribution Mode ........... SRC/DST MAC
4 - Port Range ..................
M - Modify Aggregator
R - Return to Previous Menu
Enter your selection?
