Chapter 23: STP and RSTP
Section IV: Spanning Tree Protocols 472
Displaying STP
Port Settings
To display STP port settings, perform the following procedure:
1. From the Spanning Tree Configuration menu, type 3 to select STP
Configuration.
The STP Menu is shown in Figure 158 on page 468.
2. From the STP Menu, type P to select STP Port Parameters.
The STP Port Parameters menu is shown in Figure 159 on page
470.
3. From the STP Port Parameters menu, type 2 to select Display STP Port
Configuration.
The Display STP Port Configuration menu is shown in Figure 161.
Figure 161 Display STP Port Configuration Menu
The information in the menu is as follows:
Port - The port number.
State - Current state of the port. The possible states are Enabled
or Disabled.
Cost - Port cost of the port. The default is Auto-Update.
Priority - The number used as a tie-breaker when two or more
ports have equal costs to the root bridge.
Allied Telesyn AT-8400 Series AT-8524M - AT-S60
Production Switch
User: Manager 11:20:02 02-Jan-2004
Display STP Port Configuration
Port State Cost Priority
----------------------------------------------
1 Enabled Auto-Update 128
2 Enabled Auto-Update 128
3 Enabled Auto-Update 128
4 Enabled Auto-Update 128
5 Enabled Auto-Update 128
6 Enabled Auto-Update 128
7 Enabled Auto-Update 128
8 Enabled Auto-Update 128
N - Next Page
U - Update Display
R - Return to Previous Menu
Enter your selection?
