AT-S62 Menus Interface User’s Guide
Section II: Advanced Operations 283
The Create Policy menu is shown in Figure 95.
Figure 95 Create Policy Menu
5. Configure the parameters as needed. The parameters are described
below:
1 - Policy ID
Specifies an ID number for the policy. Every policy on the switch
must be assigned a unique number. The range is 0 to 255. The
default is 0. This parameter is required.
2 - Description
Specifies a description for the policy. The description can be from
1 to 15 alphanumeric characters. Spaces are allowed. This
parameter is optional, but recommended. Names can help you
identify the policies on the switch.
3- Remark DSCP
Specifies the conditions under which the ingress DSCP value is
overwritten. If All is specified, all packets are remarked. If None is
specified, the function is disabled. The default is None.
4 - DSCP value
Specifies a replacement value to write into the DSCP (TOS) field of
the packets. The range is 0 to 63.
A new DSCP value can be set at all three levels: flow group, traffic
class, and policy. A DSCP value specified in a flow group overrides
a DSCP value specified at the traffic class or policy level. A DSCP
value specified at the policy level is used only if no value has been
specified at the flow group and traffic class levels.
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2004
Create Policy
1 - Policy ID ............ 0
2 - Description ..........
3 - Remark DSCP .......... None
4 - DSCP value ...........
5 - Traffic Class List ...
6 - Redirect Port ........
7 - Ingress Port List ....
8 - Egress Port ..........
C - Create Policy
R - Return to Previous Menu
Enter your selection?
