Chapter 8: Port Trunking
Section I: Basic Operations 146
To delete an aggregator, perform the following procedure:
1. From the Main Menu, type 1 to select Port Configuration.
2. From the Port Configuration menu, type 4 to select Port Trunking and
LACP.
The Port Trunking and LACP menu is shown in Figure 36 on page 134.
3. Type 2 to select LACP Configuration.
The LACP (IEEE 8023ad) Configuration menu is shown in Figure 39 on
page 140.
4. Type 6 to select Delete Aggregator.
The following prompt is displayed:
Enter Aggregator Name [Max up to 20 alphanumeric
characters]:
5. Enter the name of the aggregator you want to delete. The name is
case-sensitive. You can delete only one aggregator at a time.
A confirmation prompt is displayed.
6. Type Y to delete the aggregator or N to cancel the procedure.
If you entered Yes, the aggregator is deleted.
Configuring
LACP Port
Parameters
This procedure explains how to configure a port’s priority value. This
parameter determines whether a port is active or in standby mode as
part of an aggregate trunk. For further information, refer to LACP Port
Priority Parameter on page 128. This procedure also shows how to
assign a port to a different aggregator.
Note
To remove a port from an aggregator without assigning it to a
different one, skip this procedure and instead perform Modifying an
Aggregator on page 143. When modifying the aggregator, reenter
its port list, omitting the port you want to remove.
To configure a port, perform the following procedure:
1. From the Main Menu, type 1 to select Port Configuration.
2. From the Port Configuration menu, type 4 to select Port Trunking and
LACP.
The Port Trunking and LACP menu is shown in Figure 36 on page 134.
3. Type 2 to select LACP Configuration.
