AT-S62 Menus Interface User’s Guide
Section IV: Spanning Tree Protocols 499
Creating, Deleting, and Modifying MSTIs
The following procedures explain how to create, delete, and modify
spanning tree instances.
Note
You cannot configure MSTP parameters until you have selected the
protocol as the active spanning tree protocol on the switch. For
instructions, refer to Enabling or Disabling a Spanning Tree Protocol
on page 466.
This procedure starts from the MSTP Menu. If you do not know how to
access the menu, perform steps 1 and 2 in Configuring MSTP Bridge
Settings on page 494.
1. From the MSTP Menu, type M to select MSTI Menu.
The MSTI Configuration menu is shown in Figure 174.
Figure 174 MSTI Configuration Menu
The fields in the table are defined below:
MSTI
Lists the MSTI IDs existing on the switch.
Priority
Specifies the MSTI priority value for the MSTI. The steps in this
procedure explain how you can assign this value when you create
an MSTI ID and how to modify the value for an existing MSTI ID.
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2004
MSTI Configuration
MSTI | Priority | Regional Root ID| Path Cost | Associated VLANs
---------------------------------------------------------------
1 32768 00A0D2 1454B3 0 1,2
2 32768 00A0D2 1454B3 0 4,11
1 - Create MSTI
2 - Delete MSTI
3 - Modify MSTI
U - Update Display
R - Return to Previous Menu
Enter your selection?
